PLC Input Module PLC Controller Support Source Drain Type With ARM 32-Bit Cortex-M3 CPU

Product Categories
Shanghai Flexem Technology Co.,Ltd
Contact Now

PLC Input Module PLC Controller Support Source Drain Type With ARM 32-Bit Cortex-M3 CPU

Brand Name : FLEXEM

Model Number : FL2N-24MT-4AD4TCPT

Certification : CE

Place of Origin : Shenzhen

MOQ : 1pc

Price : Negotiation

Payment Terms : T/T

Supply Ability : 5000 pcs/week

Delivery Time : 1-7 business days after payment confirmed

Packaging Details : Carton

CPU : ARM 32-bit Cortex-M3 CPU

Digital Input : 12 Input *12,supporting source/drain type

Digital Output : 12 NPN transisitor power output*12

Analog Input : 4 pass AD,12-digit isolated ADC,voltage input:0V~+10V (input impedance>500kΩ） Power input:0mA~+20mA (input Impedance=100kΩ)

User Program Memory : 200k bytes(>10k Bytes)

Involatile Data Memory : 2K Bytes

Contact Now

FL2N-24MT-4AD4TCPT-A 256 100ms timer supporting source drain type PLC input module

Description:

* CPU:ARM Cortex™-M3 CPU.
* Analog Input:4 line thermol resistor or thermocouple Thermocouple: (B,C,E,J,K,N,R,S,T model) Thermol resistor: (PT100, PT1000,Cu50, Cu100) NTC.

* Digital Input: Transistor input, supporting source drain type.

* Digital Output: NPN transistor output.

Specification:​

Digital Output 12 NPN transistor power output x12
User Program Memory 200K Bytes(>10K Bytes)
Involatile Data Memory 2K Bytes
Timer 256 100ms timer x206(0.1~3276.7 seconds),10ms timer x46(0.01~327.67 seconds), 1ms timer x4(0.001~32.767 seconds)
Counter 235
High-speed Interrupt X0-X5 rising and falling edge interruption, 3-way timing interruption

PORT1/PORT2
Pin1 Rx-(B) (PORT2 RS485) PLC Input Module PLC Controller Support Source Drain Type With ARM 32-Bit Cortex-M3 CPU
Pin2 RxD (PORT1 RS232)
Pin3 TxD (PORT1 RS232)
Pin4 NA
Pin5 GND
Pin6 Rx+(A) (PORT2 RS485)
Pin7 NA
Pin8 NA
Pin9 NA
